Angle Gauge เกจสำหรับวัดมุมชิ้นงาน

Description

Details

DESCRIPTIONS:

Used by inspectors, toolmakers, and die-sinkers for checking angles.
This gauge consists of 18 leaves with angles ranging from 1° to 45°. All numbers refer to a complimentary angle.

SPECIFICATIONS:

Code No.	Model No.	Leaves	Size Composition/Contents
03-601	No.466	18	1° 2° 3° 4° 5° 7° 8° 9° 10° 12° 14°
			14 1/2° 15° 20° 25° 30° 35° 45°
