DESCRIPTIONS:
- Wide measuring range, high accuracy, and the models are complete.
- The attached measruing joint can be run clockwise or counter-clockeise to measure te o/p torque with usual bit and the measured value will be cleared in setting time automatically.
- There are three measuring modes: Peak, Track, F. Peak for easy choice to operate.
- It can calculate and display the maximum and average torque value.
- A bulit-in o/p terminal can be connected to the computer for recalling, editing, and calculating measured datum.
SPECIFICATIONS:
Model | HP-2 | HP-10 | HP-20 | HP-50 | HP-100 | |
Kgf.cm | 0.03-0.2 | 0.15-10.0 | 0.2-20.0 | 0.75-50.0 | 1.5-100.0 | |
Measurement Range | N.m | 0.003-0.2 | 0.015-1.0 | 0.02-2.0 | 0.075-5.0 | 0.15-10.0 |
Lbf.in | 0.003-1.8 | 0.15-9.0 | 0.2-18 | 0.75-45.0 | 1.5-90.0 | |
Accuracy | Within ±5% | |||||
Power Source | 1.2V Nicd cell x 5 | |||||
Recharging Time | 8 hours with exclusive charger | |||||
Continuous use at full charge | 30 hours | |||||
Dimensions (mm) | 230(W) x 123(D) x 65(H) | |||||
Battery Life | Chargeable for 300 times or more | |||||
Weight | 1.8 kg | |||||
Exclusive Charger | Input: AC220-240V | |||||
Output: DC7.2V, 120mA |
