EP3000 Pro เครื่องแปลงไฟแบบ Pure sine wave มีระบบชาร์ตจากโซล่าเซล

Description

Details

CHARACTERISTICS:

Pure sine wave
Built in 50A PWM solar charge controller
Rated power 4kw to 6kw
3 times surge powerWide frequency 40Hz -80Hz
Compatible to generator power
Overload & short circuit protection
Smart battery charger design for optimized battery performance
Cold start function

SPECIFICATIONS:

MODEL		EP30-1KW PRO		EP30-1.5KW PRO		EP30-2KW PRO		EP30-3KW PRO
Default Battery System Voltage		12VDC	24VDC	12VDC	24VDC	12VDC	24VDC	12VDC	24VDC	48VDC
INVERTER OUTPUT	Reted Power	1.0KW		1.5KW		2KW		3KW
	Surge Rating (20ms)	3.0KVA		4.5KVA		6.0KVA		9.0KVA
	Capable Of Starting Electric Motor	1HP		1HP		1HP		2HP
	Waveform	Pure sine wave/ same as input (bypass mode)
	Nominal Output Voltage RMS	100V/110V/120VAC 220V/230V/240VAC(±10% RMS)
	Output Frequency	5OHz/60Hz±0.3 Hz
	Inverter Efficiency(Peak)	>88%
	Line Mode Efficiency	>95%
	Power Factor	1
	Typical Transfer Time	10ms(max) 10ms(max)
AC INPUT	Voltage	230VAC
	Selectable Voltage Range	96~132VAC 155~280VAC(For Personal Computers)
	Frequency Range	50Hz/60Hz (Auto sensing) 40~80Hz
BATTERY	Minimum Start Voltage	10.0VDC /10.5VDC for12VDC mode (*2 for 24VDC, )
	Low Battery Alarm	10.5VDC±0.3V for12VDC mode (*2 for 24VDC, )
	Low Battery Cutoff	10.0VDC±0.3V for12VDC mode (*2 for 24VDC, )
	High Voltage Alarm	16.0VDC±0.3V for12VDC mode (*2 for 24VDC, )
	High Battery Voltage Recover	15.5VDC±0.3V for12VDC mode (*2 for 24VDC, )
	Idle Consumption-Search Mode	<25W when power saver on
CHARGER	Output Voltage	Depends on battery tvpe
	Charger AC Input Breaker Rrating	10A		30A		30A		30A
	Overcharge Protection S.D.	15.7VDC for 12VDC mode (*2 for 24VDC mode)
	Maximum Charge Current	35A	20A	45A	25A	65A	35A	75A	45A	30A
BYPASS & PROTECTION	Input Voltage Waveform	Sine wave (grid or generator)
	Nominal Input Frequency	50Hz or 60Hz
	Overload Protection (SMPS Load)	Circuit breaker
	Output Short Circuit Protection	Circuit breaker
	Bypass Breaker Rating	10A		30A		30A		30A
	Max Bypass Current	30Amp
SOLAR CHARGER	Maximum PV Charge Current	50A
	DC Voltage	12V/24V/48
	PWM Range @ Operating Voltage	15~80VDC
	Maximum PV Array Open Circuit Voltage	90VDC
	Maximum Efficiency	>97%
	Standby Power Consumption	<2W
MECHANICAL SPECIFICATIONS	Mounting	Wall mount
	Dimensions (WHD)	426206178 mm
	Net Weight (Solar CHG) kg	16.5		17		21.1	20	26	24.5	24.8
	Shipping Dimensions(WHD)	570335300mm
	Shipping Weight (Solar CHG) kg	19.3		20		24.1	22.8	29.1	27.5	27.5
OTHER	Operation Temperature Range	0°C to 40°C
	Storage Temperature	-15°C to 60°C
	Audible Noise	60dB MAX
	Display	LED+LCD
	Standard Warranty	1 year
