Description
Details
Features:
- Air-free dispensing
- Snuff-back prevents post-dispense dripping
- Simple load mechanism also provides easy cleaning
- Manual or Timed modes
- Large digital LED display
- Clean room compatible
Specifications:
Weight | 6.6lbs (3kg) |
Input Voltage | 110 - 240V models 50 / 60 Hz |
Dispense time | 0.01 - 99.99 seconds |
Internal Voltage | 5VDC |
Cycle initiation | continuous & timed |
Rotor Speed | up to 120 rpm (max) |
Flow Speed | 0.01 - 6ml/min. (Teflon tube) |
0.1 - 20ml/min. (Silicone tube) | |
Dispense pressure | over 1.5kg / cm2 |
Direction of pump | both direction (Forward / Reverse) |
Snuff - back | programmable by reveres rotation |
Digital display | time count down |
I/O | connection for remote operation |
Accessories (included)
Part# | Qty | Description |
562030-T | 1 | standard pump head |
560989-D | 1 | nozzle holder (with switch) |
561010-D | 1 | nozzle 1.7mm diameter |
561011-D | 1 | nozzle 2.1mm diameter |
561012-D | 1 | nozzle 2.6mm diameter |
561013-D | 1 | nozzle 3.5mm diameter |
560984P | 1 | hose 1 meter (3.28ft) 1.0 x 1.6mm |
560985P | 1 | hose 1 meter (3.28ft) 1.4 x 2.0mm |
560995P | 1 | hose 1 meter (3.28ft) 1.9 x 2.5mm |
560996A | 1 | hose 1 meter (3.28ft) 2.4 x 3.0mm |
562031-D | 1 | 9-pin connector |
562032-D | 1 | foot pedal (optional - not included) |
