Product Applications
- Household Appliances: compact microwave ovens, bread makers, food processors, small bar refrigerators, small vacuum cleaners, fluorescent and incandescent lights, sewing machines and fans
- Power Tools: drills, jigsaws, sanders and buffers
- Entertainment Electronics: televisions, VCRs, video games, stereos, musical instruments and satellite equipment
- LED display shows output power and watt consumption
Specifications:
Model No. | KSC-500W | ||
Output | AC Voltage | 220V | |
Rated Power | 500W | ||
Peak Power | 1000W | ||
Waveform | Pure sine wave(THD<3%) | ||
Frequency | 50 or 60Hz(±2%) | ||
LED Indicator | Green LED for power on | ||
Red LED Fault Status | |||
Input | No Load Current Draw | <0.5A | |
DC Voltage | 12V | ||
Voltage Range | 10.5~15.0VDC | ||
Efficiency | about 90% | ||
Charger | Max circuit charger | 12V | 10A |
Feature | Automatic switching | ||
Protection | Bat. Low Alarm | 10.5V | |
Bat. Low Shutdown | 10.0V | ||
Over Load | Shut off output voltage, re-power on to recover | ||
Over Voltage | 15.5+/-0.5V | ||
Over Temperature | Shut off output voltage, re-power automatically after temperature goes down | ||
Output Short | Shut off output voltage, re-power on to recover | ||
Environment | Working Temp. | 0~+40°C | |
Working Humidity | 20% ~ 90% RH non-condensing | ||
Storage Tem. Humidity | -30°C~+70°C/22°F~+158°F | ||
Others | Dimension | 440×410×330mm(L×W×H) | |
Packing | 13.1+/-0.5 kg | ||
Application | Home and Office appliances, Power tools and Portable equipment, Vehicle, Yacht and Solar power system… |
