FEATURES:
- Double integral A/D conversion
 - Designed for field professionals
 - Full overload protection
 - Low battery display indication
 - 6000 counts (3 6/7 digits) Large LCD Display
 - Full function protection, anti-high voltage circuit design.
 - Low battery display indication
 - Full overload protection
 - Unit symbol display and 61 selection analog bar display
 - With automatic polarity
 - With hard sealed IC
 - Selectable between °C and °F
 - Relative Value, Frequency/Duty cycle, transistor measuring and data hold

 SPECIFICATIONS:
- Display: 6000 (3 6/7) digits Large LCD with automatic polarity, unit symbol and 61 selection analog display
 - Measuring method: double integral A/D Conversion
 - Sampling Rate: approx. 3 Times / Second
 - Over range indication: "OL" displayed in the highest digit
 - Low battery display symbol
 - Operating Temperature: 0 ~ 40 °C; Operating Humidity: <80%RH
 - Storage Temperature: -10 ~ 40 °C; Storage Humidity: below 80% RH
 - Safety Standards: CE, IEC1010, double insulation II
 - Power: 2 x 1.5 V AAA batteries (included)
 - Dimensions: 185 (L) x 93 (W) x 35 (H) mm
 - Weight: approx. 290g (batteries included)
