FEATURES:
- Magnetic induction method (ISO 2178, ASTM D7091), Measurement of non-magnetic coatings on magnetic substrates.
- Quick one-hand operation. Place instrument on specimen and see the measured value.
- Ready to measure immediately without calibration.
- Easy to perform zero-point correction provides correct measurement results for measuring applications with little changes in shape and substrate material.
- The one-point calibration function allows for an adaptation in cases of severe changes in shape or substrate material.
- Data transmitting to PC via USB cable.
- Statistic function allows for evaluation of a measurement series and display of the most significant characteristic statistical values.
SPECIFICATIONS:
- Test Method: Magnetic induction
- Measuring Range: 0~1500µm (0 ~60 mil)
- Resolution: 0 ~ 999µm: 0.1µm, ≥1000µm: 1µm
- Accuracy: 0 ~ 100µm: ±1.5µm , 101 ~ 1500µm: ≤ ±1.5 %
- Data Memory: 1500 readings
- Display: Matrix LCD with Backlight
- Power: 1.5V*3 (AAA alkaline batteries)
- Printer: Wireless Mini-printer(optional)
- Dimensions: 88 X 67 X 30 mm
- Weight: 160gr
- Certificate: CE
