FEATURES:
- Accuracy: ±1% of indicated value 1 increnment, over the full range
- Display: torque reading 4-digit LCD diplay
- Measurement modes: Pack hole Pack to peak-hold Run
- Directionof measurement: Automatic CW/CCW changeover, provided with CW/CCW status display
- Power suppy: two rechargeable "AA" 1.2V batteries and a 100-240V battery charger
- Battery life: Approximately 20 hours with fully charged batteries (continuous operation)
- Power off: Auto power-off, approximately 3 minutes 40 seconds
- Tolerance setting: Automatic judgement capability per the Min/Max settings
- Data memory: 100 pieces of data
- Output: Printer output (exclusively to a TPK-3), analog output << 0 to 1.024 (mid point) to 2.048 V >>
Model available:
Model | Range (CW/CCW) | Increment | Weight (kg) | Standard Bit (+) Pahillips SB Type |
DTDK-20EXL | 2~20 kgf-cm | 0.01 kgf-cm | 1.0 | No.0, No.1 |
DTDK-50EXL | 5~50 kgf-cm | 0.05 kgf-cm | 1.0 | No.1, No.2 |
DTDK-N2EXL/DTDK-CN200EXL | 20~200 kgf-cm | 0.1 cN-m | 1.0 | No.0, No.1 |
DTDK-N2EXL/DTDK-CN500EXL | 50~500 kgf-cm | 0.5 cN-m | 1.0 | No.1, No.2 |
