DESCRIPTIONS:
As a special precision measuring equipment, ST Series Digital Torque Meter is R&D for testing and measuring many kinds of torque. The Meter is applied with the measured and calibrated torque of motorize or air-driving clamps, torque screwdriver and torque spanner.
FEATURES:
- Peak holding and auto-releasing function: Catching and holding the peak value in test, the peak holding time can be set(1-10 seconds);
- Automatic power off function: This function saves battery and keeps the gauge safe, also the power off time(1-60minutes) can be set By yourself;
- Comparing function: Initial input of the tolerance limit(Max/Min)enables the device to judge the measured result as Go(Green pilot lamp)/NG(Red pilot lamp);
- Memory function: Memory 10 testing data, and calculate the average;
- Three units conversion: Converting three units(N.m, kgf.cm, ibf.in) automatically;
- RS-232C output: Connecting outside equipment and using the related CD for transmitting the tested data to computer for relevant treatment.
- Test ramge: 1N.m to 500N.
SPECIFICATIONS:
Models | ST-1 | ST-2 | ST-5 | ST-10 | ST-20 |
Capacity (N.m) | 1 | 2 | 5 | 10 | 20 |
Resolution (N.m) | 0.0005 | 0.001 | 0.002 | 0.005 | 0.01 |
Sensor Conformation | Sensor inside | ||||
Testing Speed | 5000rpm | ||||
Power | 8.4V 1.2Vx 7 Nickl Hydride Battery | ||||
Charging time | About 4 hours | ||||
Battery Operating time | About 12 hours | ||||
Battery life | 300 time | ||||
Adaptor | Inpout:AC 220V50Hz Output:DC 12V 300mA | ||||
Accuracy | ±0.5%FS | ||||
Weight | About 2.4kg |
