DESCRIPTIONS:
ST Series Digital Torque Meter is R&D for testing and measuring many kinds of torque. The Meter is applied with the measured and calibrated torque of motorize or air-driving clamps, torque screwdriver and torque spanner.
FEATURES:
- Peak holding and auto-releasing function: Catching and holding the peak value in test, the peak holding time can be set (1-10 seconds).
- Automatic power off to saves battery and keeps the gauge safe, also the power off time (1-60minutes) can be set by yourself.
- Initial input of the tolerance limit (Max/Min) enables the device to judge the measured result as Go (Green pilot lamp)/NG (Red pilot lamp).
- Memory 10 testing data, and calculate the average.
- Converting three units (N.m, Kgf.cm, Lbf.in) automatically.
- Communicate by RS-232C connect computer to read a data, record a data and graph mode.
- Capability testing range: 0-20N.m
SPECIFICATIONS:
Models | ST-1 | ST-2 | ST-5 | ST-10 | ST-20 |
Capacity (N.m) | 1 | 2 | 5 | 10 | 20 |
Resolution (N.m) | 0.0005 | 0.001 | 0.002 | 0.005 | 0.01 |
Sensor Conformation | Sensor inside | ||||
Testing Speed | 5000rpm | ||||
Power | 8.4V 1.2Vx 7 Nickl Hydride Battery | ||||
Charging time | About 4 hours | ||||
Battery Operating time | About 12 hours | ||||
Battery life | 300 time | ||||
Adaptor | Inpout:AC 220V50Hz Output:DC 12V 300mA | ||||
Accuracy | ±0.5%FS | ||||
Weight | About 2.4kg |
