FEATURES:
- Economic Value Models.
- High stability, Not impact of voltage changes, free from fatique under long-time using.
- Small, light body, specially design for the precise needing of tiny screws.
- Torque accuracy and stability, rotation speed selected by switches Hi & Lo.
- Best applied to Small appliances, Electronics, Toys, Processing and Assembly industry.
SPECIFICATIONS:
MODEL | BSD-101 | BSD-102 | BSD-102F | |
Input voltage(DC) | 36VDC | |||
Rated input | 36W | 45W | ||
Bit torque | Kgf.cm | 0.51-15.30 | 4.08-35.71 | 5.10-30.60 |
Lbf.in | 0.44-13.28 | 3.54-30.98 | 4.43-26.55 | |
N.m | 0.05-1.50 | 0.40-3.50 | 0.50-3.00 | |
Torque Adjustment | Step less | |||
Unload Speed (RPM) | 1100 | 1000 | 2000 | |
Assembly screw (mm) | Machine | 1.6-4.0 | 2.6-5.0 | 2.6-5.0 |
Tapping | 1.6-3.0 | 2.6-4.0 | 2.6-4.0 | |
Weight (g) | 445 | 510 | 510 | |
Length (mm) | 220 | 230 | 230 | |
Power controller | BSD-36P | BSD-36P-60W | BSD-36P-60WF |
